Model: Ara X5
Operating System: Pre-installed Windows 10
CPU: Cherry Trail Z8300 14nm 1.8G 64-bit Quad core
GPU: Gen 8 Graphics
RAM: 2GB DDR3L
ROM: eMMC 32G
Wifi Connectivity: Wi-Fi 802.11 a/b/g/n 2.4Ghz/5Ghz
Video Supported: HD MPEG1/2/4,H.264, H.265,HD AVC/VC-1,RM/RMVB,Xvid/DivX3/4/5/6 ,RealVideo8/9/10
Audio Supported: MP3,WMA,AAC,WAV,OGG,AC3,DDP,True HD,DTS,DTS,HD,FLACAP
Picture Supported: JPEG,BMP,GIF,PNG,TIFF,etc.
HDMI Port: Standard HDMI female
Other Interfaces: USB2.0 x 2, USB3.0 x 1, Audio out&Mic-i x 1, LAN(100MB)*1, HDMI Type A *1, Power Button*1, Micro SD Slot*1, DC-IN*1
Other Function: Status Indicator; White LED lights(power on); White LED lamp(power off)
Wake On LAN: NO
Dimension & Weight (Main Product)
1 x TV box
1 x HDMI cable
1 x UK Power adapter
1 x User manual14nm Cherry Trail Z8300: As the pioneer in Mini PC market, Tronsmart is the first brand to feature Ara X5 with Intel Cherry Trail CPU: Z8300. Z8300, the premier Intel Atom CPU, stepped out to apply 14nm Soc technology, next generation micro architecture which leads the market for approximate 2 years. It is also equipped with 1.8G 64-bit Quad core CPU as well as Gen 8 graphics.
Pre-installed Windows 10: Tronsmart Ara X5 is pre-installed with licensed Windows 10 home, so that our users can enjoy the advanced functions of Windows OS directly. Moreover, the built-in Cortana in Windows 10 can turn Ara X5 into a work assistant as well as life-partner. With Windows 10 OS, you can sync game display to any devices of Windows 10 OS. What an amazing scenario! When your friends are watch football matches on TV, , you can play games on Xbox and display on another PC screen.
Fanless Design: With fanless design, Ara X5 offers quiet but stable system performances, with embedded systems performing steady heat dissipation under industrial automation control. Ara X5 utilizes high performance dual-layer PCBA, characterizing of heat sink design. Even through its fanless, it still extends desirable temperature control performance on CPU.
Acrylic Panel: Continuing on Ara BJ19 design, Ara X5 adopts Acrylic panel and the whole mould structure design, but with much thinner, lighter figure. AP6330: Thanks to the Broadcomm AP6330 Wi-Fi module, Ara X5 supports 802.11 a/b/g/n 2.4Ghz/5Ghz and embedded with BT 4.0 module, it can save more power consumption and reduces 3-milliseconds delay, with transfer-distance over 10 meters, apart from AES-128 coding support. It is compatible with 2.0, 2.1 and 3.0, all BT standards
2G+32G eMMC: Tronsmart Ara X5 2GB DDR3 RAM, and 32GB eMMC Flash, advantageous in performance, security and reliability contributed by the eMMC memory, ultimately delivering a richer end-user experience.
